Wagner Tuning Audi S4/S5 B9 Competition Intercooler Kit – 200001120.KITSINGLE
Upgrade the cooling performance of your Audi S4 B9 or Audi S5 F5 3.0 TFSI with the Wagner Tuning Competition Intercooler Kit. Designed for improved airflow, reduced intake temperatures, and enhanced engine efficiency, this high-performance intercooler system is ideal for both street and motorsport applications.
Vehicle Compatibility
Compatible with:
- Audi S4 B9 3.0 TFSI – 260KW / 354PS (2016+)
- Audi S5 F5 3.0 TFSI – 260KW / 354PS (2016+)
Included mounting brackets are suitable for EU models only.
Key Features
- Competition-Grade Intercooler Upgrade
- 134% Larger Frontal Area Compared to OEM
- 105% More Volume Than Factory Intercooler
- High-Efficiency Tube and Fin Core Design
- CFD-Optimized Cast Aluminum End Tanks
- Internal Turbulator Technology
- Reduced Pressure Drop Compared to OEM
- Anti-Corrosion Thermal Coating
- Plug and Play Installation
- Lightweight High-Performance Construction
- Optional Charge Air Piping Upgrade Available
Intercooler Specifications
Wagner Tuning Competition Intercooler
- Dimensions: 550mm x 445mm x 70mm
- Volume: 17.13 Liters
- Cooling Surface Area: 2447 cm²
- Weight: Approximately 9.5kg
- Inlet Diameter: Ø62mm
- Outlet Diameter: Ø67mm
OEM Intercooler
- Dimensions: 720mm x 145mm x 80mm
- Volume: 8.35 Liters
- Cooling Surface Area: 1044 cm²
Enhanced Cooling Performance
The Wagner Tuning Competition Intercooler features a significantly larger core and optimized airflow design compared to the factory intercooler system. The increased cooling surface and charge air volume help reduce intake air temperatures while improving airflow efficiency and engine response.
CFD-optimized cast aluminum end tanks and internal turbulators improve airflow distribution and reduce airflow restrictions commonly found in OEM intercoolers.
Premium Construction
Manufactured using high-quality tube and fin intercooler cores, the system is built for reliable operation under high-performance conditions. The anti-corrosion coating supports effective heat dissipation while protecting the intercooler from environmental wear.
Optional Charge Pipe Upgrade
This kit is optionally available with a complete charge air piping upgrade, including:
- 1 Black Coated Aluminum Charge Pipe
- 3 Reinforced Black Silicone Hoses
Package Includes
- 1 Competition Intercooler (Black Coated)
- 1 Aluminum Charge Pipe (Optional)
- 3 Reinforced Silicone Hoses (Optional)
- Mounting Hardware
- Installation Instructions
Installation
- 100% Plug and Play Fitment
- Direct OEM Replacement
- Easy Installation
The Wagner Tuning Audi S4/S5 B9 Competition Intercooler Kit is an excellent upgrade for drivers seeking lower intake temperatures, improved airflow efficiency, and enhanced performance for the Audi 3.0 TFSI platform.
